1452003
ActivePhoenix Contact
CHARX T1HBI12-1AC80DC200-10M1
1452003
ActivePhoenix Contact
CHARX T1HBI12-1AC80DC200-10M1
Description
General part information
1452003
32.81' (10.00m) Power Cord Green-Yellow, Orange 62196-2 (Type 1), 62196-3 (Type 1) To Cable
Technical Specifications
Parameters and characteristics for this part
| Specification | 1452003 |
|---|---|
| 1st Connector | 62196-2 (Type 1), 62196-3 (Type 1) |
| 2nd Connector | Cable |
| Color | Orange, Green-Yellow |
| Conductor Types | Power, Signal |
| Current Rating Options | 80A, 2A |
| Length | 32.81 ft |
| Number of Conductors - Power | 5 |
| Number of Conductors - Signal | 2 |
| Operating Temperature (Max) | 60 °C |
| Operating Temperature (Min) | -40 °C |
| Shielding | Unshielded |
| Style | Leads, Female Plug |
| Voltage Rating (AC) | 250 VAC, 30 VAC |
