SCT-0400-010
ActiveAim Dynamics
0.4" SPLIT-CORE CT 10A:333MV
SCT-0400-010
ActiveAim Dynamics
0.4" SPLIT-CORE CT 10A:333MV
Description
General part information
SCT-0400-010
Current Sensor 10A 1 Channel Current Sensor Unidirectional Module, Single Pass Through
Technical Specifications
Parameters and characteristics for this part
| Specification | SCT-0400-010 |
|---|---|
| Accuracy | 1 % |
| Current - Sensing | 10 A |
| For Measuring | AC |
| Frequency (Max) | 1 kHz |
| Frequency (Min) | 50 Hz |
| Linearity Tolerance | 1 % |
| Mounting Type | Free Hanging |
| Number of Channels | 1 |
| Operating Temperature (Max) | 75 °C |
| Operating Temperature (Min) | -20 °C |
| Output | Voltage, Ratiometric |
| Package / Case | Module, Single Pass Through |
| Polarization | Unidirectional |
| Sensor Type | Current Sensor |
