8132S-16.384NQ33DTK
ActiveSuzhou Hangjing Elec&Tech Co.,Ltd
TCXO 3225,16.384MHZ,CLIPPED SINE
8132S-16.384NQ33DTK
ActiveSuzhou Hangjing Elec&Tech Co.,Ltd
TCXO 3225,16.384MHZ,CLIPPED SINE
Description
General part information
8132S-16.384NQ33DTK
16.384 MHz XO (Standard) Clipped Sine Wave Oscillator 3.3V Enable/Disable 4-SMD, No Lead
Technical Specifications
Parameters and characteristics for this part
| Specification | 8132S-16.384NQ33DTK |
|---|---|
| Base Resonator | Crystal |
| Frequency | 16.384 MHz |
| Frequency Stability | 0.5 ppm |
| Function | Enable, Disable |
| Height - Seated (Max) | 0.035 in, 0.043 in |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Output | Clipped Sine Wave |
| Package / Case | 4-SMD, No Lead |
| Package Length | 3.2 mm |
| Package Name | 4-VDFN |
| Package Width | 2.5 mm |
| Size / Dimension Length | 0.126 in |
| Size / Dimension Width | 0.098 in |
| Type | TCXO, XO (Standard) |
| Voltage - Supply | 3.3 V |
