PFN.2M.310.XLMT

Active

LEMO

CONN RCPT FMALE 10POS GOLD CRIMP

Search across all available documentation for this part.

Active

LEMO

CONN RCPT FMALE 10POS GOLD CRIMP

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	PFN.2M.310.XLMT	PFN.2M Series

Applications	Military, Aerospace, Automotive, Aviation	Military, Aerospace, Automotive, Aviation
Cable Opening [custom]	0.512 in	0.512 in
Cable Opening [custom]	13 mm	13 mm
Color	Gray	Gray
Connector Type	Receptacle, Female Sockets	Receptacle, Female Sockets
Contact Finish - Mating	Gold	Gold
Contact Finish Thickness - Mating	59 Áin	59 Áin
Contact Finish Thickness - Mating	1.5 Ám	1.5 Ám
Contact Material	Bronze	Bronze
Current Rating (Amps)	8 A	4 - 8 A
Ingress Protection	IP68 - Dust Tight, Waterproof	IP68 - Dust Tight, Waterproof
Insert Material	Polyetheretherketone (PEEK)	Polyetheretherketone (PEEK)
Mounting Feature	Flange	Flange
Mounting Type	Free Hanging (In-Line), Panel Mount	Free Hanging (In-Line), Panel Mount
Number of Positions	10	10 - 19
Operating Temperature [Max]	200 °C	200 °C
Operating Temperature [Min]	-55 °C	-55 °C
Orientation	N	N
Primary Material	Metal	Metal
Shell Finish	Nickel	Nickel
Shell Material	Aluminum Alloy	Aluminum Alloy
Shell Size - Insert	310	310 - 319
Shielding	Shielded	Shielded
Termination	Crimp	Crimp

CONN RCPT FMALE 10POS GOLD CRIMP

Part	Mounting Feature	Color	Primary Material	Termination	Insert Material	Contact Finish - Mating	Ingress Protection	Contact Material	Shielding	Shell Finish	Operating Temperature [Min]	Operating Temperature [Max]	Connector Type	Number of Positions	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Shell Size - Insert	Shell Material	Current Rating (Amps)	Applications	Orientation	Mounting Type	Cable Opening [custom]	Cable Opening [custom]
LEMO PFN.2M.310.XLMM	Flange	Gray	Metal	Crimp	Polyetheretherketone (PEEK)	Gold	IP68 - Dust Tight, Waterproof	Bronze	Shielded	Nickel	-55 °C	200 °C	Receptacle, Female Sockets	10	59 Áin	1.5 Ám	310	Aluminum Alloy	8 A	Aerospace, Automotive, Aviation, Military	N	Free Hanging (In-Line), Panel Mount	0.512 in	13 mm
LEMO PFN.2M.310.XLMT	Flange	Gray	Metal	Crimp	Polyetheretherketone (PEEK)	Gold	IP68 - Dust Tight, Waterproof	Bronze	Shielded	Nickel	-55 °C	200 °C	Receptacle, Female Sockets	10	59 Áin	1.5 Ám	310	Aluminum Alloy	8 A	Aerospace, Automotive, Aviation, Military	N	Free Hanging (In-Line), Panel Mount	0.512 in	13 mm
LEMO PFN.2M.319.XLMT	Flange	Gray	Metal	Crimp	Polyetheretherketone (PEEK)	Gold	IP68 - Dust Tight, Waterproof	Bronze	Shielded	Nickel	-55 °C	200 °C	Receptacle, Female Sockets	19	59 Áin	1.5 Ám	319	Aluminum Alloy	4 A	Aerospace, Automotive, Aviation, Military	N	Free Hanging (In-Line), Panel Mount	0.512 in	13 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

10 Position Circular Connector Receptacle, Female Sockets Crimp
