568
ObsoleteKeystone Electronics
CONN RCA JACK MONO 3.2MM PCB
568
ObsoleteKeystone Electronics
CONN RCA JACK MONO 3.2MM PCB
Description
General part information
568
3.20mm ID, 9.00mm OD (RCA) Phono (RCA) Jack Mono Connector Rivet
Technical Specifications
Parameters and characteristics for this part
| Specification | 568 |
|---|---|
| Body Color | Silver |
| Body Material | Steel |
| Connector Type | Phono (RCA) Jack |
| Contact Material | Brass |
| Gender | Female |
| Industry Recognized Mating Diameter (ID) | 3.2 mm |
| Industry Recognized Mating Diameter (OD) | 9 mm |
| Insulation Color | Red |
| Internal Switch(s) | Does Not Contain Switch |
| Mating Length/Depth | 0.562 in |
| Mounting Type | Through Hole |
| Number of Conductors | 2 Conductors |
| Number of Contacts | 2 Contacts |
| Shielding | Unshielded |
| Signal Lines | Mono |
| Termination | Rivet |
