1619918
ActivePhoenix Contact
CONN RCPT FMALE 17POS GOLD SLDR
1619918
ActivePhoenix Contact
CONN RCPT FMALE 17POS GOLD SLDR
Description
General part information
1619918
17 (Power) Position Circular Connector Receptacle, Female Sockets Solder
Technical Specifications
Parameters and characteristics for this part
| Specification | 1619918 |
|---|---|
| Color | Silver |
| Connector Type | Receptacle, Female Sockets |
| Contact Finish - Mating | Gold |
| Contact Material | Copper Zinc |
| Fastening Type | Push-Twist |
| Ingress Protection Description | Waterproof, Dust Tight |
| Ingress Protection IP Rating | IP67 |
| Insert Material | PBT, Polybutylene Terephthalate |
| Mounting Feature | Flange |
| Mounting Type | Panel Mount, Through Hole |
| Number of Positions | 17 |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Orientation | N (Normal) |
| Position Types | Power |
| Primary Material | Metal |
| Shell Material | Copper Zinc |
| Shell Size - Insert | M23-17 |
| Shielding | Shielded |
| Termination | Solder |
