Description
General part information
DK-BULK-1476-SB-WH-50
8 (4 Pair Twisted) Conductor Multi-Pair, Cat6a Cable White 23 AWG 50.00' (15.24m)
Technical Specifications
Parameters and characteristics for this part
| Specification | DK-BULK-1476-SB-WH-50 |
|---|---|
| Cable Type | Multi-Pair, Cat6A |
| Conductor Arrangement | Twisted |
| Conductor Insulation | Polyolefin (PO) |
| Conductor Material | Annealed Bare, Copper |
| Features | Flame Retardant, Rip Cord, UV Resistant |
| Jacket (Insulation) Diameter | 0.245 in |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC), Riser |
| Jacket Color | White |
| Length | 50 ft |
| Number of Conductors | 8 |
| Number of Conductors - Pair | 4 |
| Operating Temperature (Max) | 75 °C |
| Operating Temperature (Min) | -35 °C |
| Ratings | 1666, Style, UL |
| Usage | Video, LAN, Ethernet |
| Voltage | 300 V |
| Wire Gauge | 23 AWG |
