152574-1

Obsolete

Beyond LED Technology

LED ENG CL WHT LNR STRIP 5000K

Search across all available documentation for this part.

Obsolete

Beyond LED Technology

LED ENG CL WHT LNR STRIP 5000K

Technical Specifications

Parameters and characteristics for this part

Specification	152574-1

CCT (K)	5000 K
Color	Cool, White
Configuration	Linear Light Strip, Plug and Play
CRI (Color Rendering Index)	80
Features	IP22
Height [z]	35.05 mm
Lens Type	Domed
Lumens/Watt @ Current - Test	140 lm/W
Luminous Flux @ Current/Temperature	12600 lm
Size / Dimension	2374.9 mm
Type	LED Engine
Viewing Angle	120 °
Voltage - Forward (Vf) (Typ)	188.5 VAC

LED ENG CL WHT LNR STRIP 5000K

Part	Lumens/Watt @ Current - Test	Luminous Flux @ Current/Temperature	Height [z]	Viewing Angle	Features	CRI (Color Rendering Index)	Voltage - Forward (Vf) (Typ)	Configuration	Size / Dimension	CCT (K)	Lens Type	Color	Type
Beyond LED Technology 152574-1	140 lm/W	12600 lm	35.05 mm	120 °	IP22	80	188.5 VAC	Linear Light Strip, Plug and Play	2374.9 mm	5000 K	Domed	Cool, White	LED Engine

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 231.99

General part information

LED Lighting COBs Engines Modules LED Engine - White, Cool Linear Light Strip, Plug and Play
