PCSLF1045-102M-RC
ActiveAllied Components International
1000UH +/-20% PWR CHIP INDUCTOR
PCSLF1045-102M-RC
ActiveAllied Components International
1000UH +/-20% PWR CHIP INDUCTOR
Description
General part information
PCSLF1045-102M-RC
1 µH Shielded Inductor 290 mA 2.8Ohm Max Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | PCSLF1045-102M-RC |
|---|---|
| Current - Saturation (Isat) | 0.32 mA |
| Current Rating | 0.29 A |
| DC Resistance (DCR) (Max) | 2.8 Ohm |
| Height - Seated (Max) | 0.189 in |
| Inductance | 1 µH |
| Inductance Frequency - Test | 1 MHz |
| Material - Core | Ferrite |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Nonstandard |
| Shielding | Shielded |
| Size / Dimension Length | 0.398 in |
| Size / Dimension Width | 0.398 in |
| Tolerance | 20 % |
