TSC-100-AFC-060

Active

ATC-Diversified Electronics

RELAY TIME DELAY 60SEC 1A 120V

Search across all available documentation for this part.

Active

ATC-Diversified Electronics

RELAY TIME DELAY 60SEC 1A 120V

Technical Specifications

Parameters and characteristics commom to parts in this series

RELAY TIME DELAY 10SEC 1A 120V

Part	Termination Style	Voltage - Supply [Max]	Voltage - Supply [Min]	Timing Initiate Method	Mounting Type	Function	Timing Adjustment Method	Delay Time [Min]	Delay Time [Max]	Relay Type	Contact Rating @ Voltage
ATC-Diversified Electronics TSC-100-ARC-010	Quick Connect	240 VDC, 240 VAC	12 V, 24 VAC	Input Voltage	Chassis Mount	On-Delay	External Resistor	0.1 Sec	10 s	Solid State Relay	1 A, 120 VAC
ATC-Diversified Electronics TSC-100-AFC-060	Quick Connect	240 VDC, 240 VAC	12 V, 24 VAC	Input Voltage	Chassis Mount	On-Delay	Fixed	0.6 Sec	60 Sec	Solid State Relay	1 A, 120 VAC

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 179.69

General part information

On-Delay Time Delay Relay SPST-NO (1 Form A) 0.6 Sec ~ 60 Sec Delay 1A @ 120VAC Chassis Mount

Technical documentation and resources

No documents available
