Description
General part information
SCT520PT3.15A250V
3.15A 500 VAC 500 VDC Fuse Cartridge Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | SCT520PT3.15A250V |
|---|---|
| Applications | Electrical, Industrial |
| Approval Agency | CQC, cURus |
| Breaking Capacity (AC) | 200 A |
| Breaking Capacity (DC) | 500 A |
| Current Rating | 3.15 A |
| Fuse Type | Cartridge |
| Melting I²t | 74 |
| Mounting Type | Through Hole |
| Package / Case Interfaces | Axial |
| Package Features | Axial |
| Package Height | 0 mm |
| Package Length | 5 mm |
| Package Name | 5mm x 20mm |
| Package Width | 20 mm |
| Response Time | Slow Blow |
| Size / Dimension Diameter | 0.205 in |
| Size / Dimension Length | 0.787 in |
| Voltage Rating - AC | 500 V |
| Voltage Rating - DC | 500 V |
