ACB-12-H-15A
ActiveOptiFuse
HOR. BRACKET-TYPE I AUTO,15A 12V
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
ACB-12-H-15A
ActiveOptiFuse
HOR. BRACKET-TYPE I AUTO,15A 12V
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | ACB-12-H-15A | ACB-12 Series |
|---|---|---|
| Actuator Type | Automatic Reset | Automatic Reset |
| Approval Agency | SAEJ553 | SAEJ553, cURus, IP 40 |
| Breaker Type | Shortstop | Shortstop |
| Current Rating (Amps) | 15 A | 8 - 50 A |
| Illumination | None | None |
| Number of Poles | 1 | 1 |
| Voltage Rating - DC | 12 V | 12 V |
ACB-12 Series
NO BRACKET-TYPE I AUTO, 15A 12V
| Part | Number of Poles | Illumination | Voltage Rating - DC | Actuator Type | Breaker Type | Current Rating (Amps) | Approval Agency |
|---|---|---|---|---|---|---|---|
OptiFuse ACB-12-N-15A | 1 | None | 12 V | Automatic Reset | Shortstop | 15 A | SAEJ553 |
OptiFuse ACB-12-N-30A | 1 | None | 12 V | Automatic Reset | Shortstop | 30 A | SAEJ553 |
OptiFuse ACB-12-H-40A | 1 | None | 12 V | Automatic Reset | Shortstop | 40 A | SAEJ553 |
OptiFuse ACB-12-N-10A | 1 | None | 12 V | Automatic Reset | Shortstop | 10 A | SAEJ553 |
OptiFuse ACB-12-H-35A | 1 | None | 12 V | Automatic Reset | Shortstop | 35 A | SAEJ553 |
OptiFuse ACB-12-N-8A | 1 | None | 12 V | Automatic Reset | Shortstop | 8 A | cURus, IP 40 |
OptiFuse ACB-12-N-35A | 1 | None | 12 V | Automatic Reset | Shortstop | 35 A | SAEJ553 |
OptiFuse ACB-12-H-10A | 1 | None | 12 V | Automatic Reset | Shortstop | 10 A | SAEJ553 |
OptiFuse ACB-12-H-50A | 1 | None | 12 V | Automatic Reset | Shortstop | 50 A | SAEJ553 |
OptiFuse ACB-12-N-25A | 1 | None | 12 V | Automatic Reset | Shortstop | 25 A | SAEJ553 |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
ACB-12 Series
Circuit Breaker Shortstop 15A AC 12 V DC Automatic Reset
Documents
Technical documentation and resources
