1710164
ActivePhoenix Contact
CONN TERMINAL BLOCK M 4 POS 5.08MM SCREW RA CABLE MOUNT 12A CARDBOARD
1710164
ActivePhoenix Contact
CONN TERMINAL BLOCK M 4 POS 5.08MM SCREW RA CABLE MOUNT 12A CARDBOARD
Description
General part information
1710164
Position Terminal Block 0.200" (5.08mm)
Technical Specifications
Parameters and characteristics for this part
| Specification | 1710164 |
|---|---|
| Color | Blue |
| Contact Mating Finish | Tin |
| Current - IEC | 12 A |
| Current - UL | 12 A |
| Number of Levels | 1 |
| Pitch | 5.08 mm |
| Positions Per Level | 4 |
| Termination Style | Screw - Rising Cage Clamp |
| Voltage - IEC | 320 V |
| Voltage - UL | 300 V |
| Wire Gauge or Range - AWG (Max) | 30 AWG |
| Wire Gauge or Range - AWG (Min) | 12 AWG |
