MXT564K305G20
ActiveCornell Dubilier Knowles
FILM/IC
MXT564K305G20
ActiveCornell Dubilier Knowles
FILM/IC
Description
General part information
MXT564K305G20
0.56 µF Film Capacitor 305V 630V Polypropylene (PP), Metallized Radial
Technical Specifications
Parameters and characteristics for this part
| Specification | MXT564K305G20 |
|---|---|
| Applications | RFI Suppression, EMI |
| Capacitance | 560 nF |
| Dielectric Material | Metallized, Polypropylene (PP) |
| Height - Seated (Max) | 0.768 in |
| Lead Spacing | 0.886 in |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 110 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Radial |
| Ratings | X2 |
| Size / Dimension Length | 1.024 in |
| Size / Dimension Width | 0.394 in |
| Termination | PC Pins |
| Tolerance | 10 % |
| Voltage Rating - AC | 305 V |
| Voltage Rating - DC | 630 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
