1943580
ActivePhoenix Contact
PLUGGABLE TERMINAL BLOCKS 7 POS 5.08MM PITCH THRU HOLE INVERT HDR
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
1943580
ActivePhoenix Contact
PLUGGABLE TERMINAL BLOCKS 7 POS 5.08MM PITCH THRU HOLE INVERT HDR
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | 1943580 | ICV Series |
|---|---|---|
| Color | Green | Green |
| Contact Mating Finish | Tin | Tin |
| Contact Tail Length | 0.142 in | 0.142 in |
| Contact Tail Length | 3.6 mm | 3.6 mm |
| Current - IEC | 16 A | 12 - 16 A |
| Current - UL | 10 A | 10 A |
| Features | Retention Latches | Retention Latches |
| Header Orientation | Vertical | Vertical |
| Housing Material | Polyamide (PA), Nylon | Polyamide (PA), Nylon |
| Insulation Height | 19 mm | 19 mm |
| Insulation Height | 0.748 in | 0.748 in |
| Material Flammability Rating | UL94 V-0 | UL94 V-0 |
| Mounting Type | Through Hole | Through Hole |
| Number of Levels | 1 | 1 |
| Number of Positions | 7 | 7 - 20 |
| Pitch [x] | 0.2 in | 0.2 in |
| Pitch [x] | 5.08 mm | 5.08 mm |
| Positions Per Level | 7 | 7 - 20 |
| Termination Style | Solder | Solder |
| Type | Header, Female Sockets | Header, Female Sockets |
| Voltage - IEC | 630 V | 630 V |
| Voltage - UL | 300 V | 300 V |
ICV Series
Pluggable Terminal Blocks 7 Pos 5.08mm pitch Thru Hole Invert Hdr
| Part | Type | Material Flammability Rating | Mounting Type | Termination Style | Pitch [x] | Pitch [x] | Insulation Height | Insulation Height | Current - UL | Number of Levels | Positions Per Level | Contact Mating Finish | Current - IEC | Contact Tail Length | Contact Tail Length | Voltage - IEC | Header Orientation | Voltage - UL | Number of Positions | Color | Housing Material | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Phoenix Contact 1825873 | Header, Female Sockets | UL94 V-0 | Through Hole | Solder | 0.2 in | 5.08 mm | 19 mm | 0.748 in | 10 A | 1 | 20 | Tin | 12 A | 0.142 in | 3.6 mm | 630 V | Vertical | 300 V | 20 | Green | Polyamide (PA), Nylon | |
Phoenix Contact 1943580 | Header, Female Sockets | UL94 V-0 | Through Hole | Solder | 0.2 in | 5.08 mm | 19 mm | 0.748 in | 10 A | 1 | 7 | Tin | 16 A | 0.142 in | 3.6 mm | 630 V | Vertical | 300 V | 7 | Green | Polyamide (PA), Nylon | Retention Latches |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
ICV Series
Pluggable Terminal Blocks 7 Pos 5.08mm pitch Thru Hole Invert Hdr
