MLSG501M100EK0A
ActiveCornell Dubilier Knowles
CAP ALUM 500UF 20% 100V FLATPACK
MLSG501M100EK0A
ActiveCornell Dubilier Knowles
CAP ALUM 500UF 20% 100V FLATPACK
Description
General part information
MLSG501M100EK0A
500 µF 100 V Aluminum Electrolytic Capacitors FlatPack, Tabbed 355mOhm @ 120Hz 5000 Hrs @ 125°C
Technical Specifications
Parameters and characteristics for this part
| Specification | MLSG501M100EK0A |
|---|---|
| Applications | General Purpose |
| Capacitance | 500 µF |
| ESR (Equivalent Series Resistance) | 355 mOhm |
| Height - Seated (Max) | 12.7 mm |
| Lead Spacing | 1 in |
| Lifetime | 5000 Hrs |
| Mounting Type | Chassis Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Tabbed, FlatPack |
| Polarization | Polar |
| Ripple Current | 5.4 A, 6.4 A |
| Size / Dimension Length | 1.5 in |
| Size / Dimension Width | 1.75 in |
| Tolerance | 20 % |
| Voltage - Rated | 100 VAC/DC |
