218-121
ActiveWAGO Corporation
PCB TERMINAL BLOCK; LOCKING SLID
218-121
ActiveWAGO Corporation
PCB TERMINAL BLOCK; LOCKING SLID
Description
General part information
218-121
21 Position Wire to Board Terminal Block 40° (130°) Angle with Board 0.098" (2.50mm) Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | 218-121 |
|---|---|
| Clamp Material | Steel |
| Clamp Plating | Nickel Plated |
| Color | Gray |
| Contact Material | Electrolytic Copper |
| Current | 4 A |
| Housing Material | Nylon 6/6, Polyamide, PA66 |
| Mating Orientation (Angle) | 40 ° |
| Mating Orientation (Angle) (Alternate) | 130 ° |
| Mating Orientation (Description) | Angle with Board |
| Mounting Type | Through Hole |
| Number of Levels | 1 |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -60 °C |
| Pitch | 0.098 in |
| Plating | Tin Plated |
| Positions Per Level | 21 |
| Voltage | 150 V |
| Wire Gauge (AWG) (Max) | 28 AWG |
| Wire Gauge (AWG) (Min) | 19.5 AWG |
| Wire Termination | Spring Cage, Screwless, Tension Clamp |
