3PS-500 Series

Part	Operating Temperature (Min)	Operating Temperature (Max)	Label Type	Color	Material	Cable O.D. (Min)	Label Width	Cable O.D. (Max)	Label Height	Label Size (Diameter)
BRADY 3PS-500-2-OR	-55 °C	135 °C	Heat Shrinkable	Orange	Polyolefin (PO)	0.25 "	2 "	0.45 "	0.85 "
BRADY 3PS-500-2-YL-S-2	-55 °C	135 °C	Heat Shrinkable	Yellow	Polyolefin (PO)	0.19 "	1 "	0.45 "		0.5 "
BRADY 3PS-500-2-RD-S-2	-55 °C	135 °C	Heat Shrinkable	Red	Polyolefin (PO)	0.19 "	1 "	0.45 "		0.5 "
BRADY 3PS-500-2-VT-S-2	-55 °C	135 °C	Heat Shrinkable	Violet	Polyolefin (PO)	0.19 "	1 "	0.45 "		0.5 "
BRADY 3PS-500-2-YL-SC
BRADY 3PS-500-2-BL-S-2	-55 °C	135 °C	Heat Shrinkable	Blue	Polyolefin (PO)	0.19 "	1 "	0.45 "		0.5 "
BRADY 3PS-500-2-VT-2	-55 °C	135 °C	Heat Shrinkable	Violet	Polyolefin (PO)	0.19 "	1 "	0.45 "		0.5 "
BRADY 3PS-500-2-BK-S-2	-55 °C	135 °C	Heat Shrinkable	Black	Polyolefin (PO)	0.19 "	1 "	0.45 "		0.5 "
BRADY 3PS-500-2-WT	-55 °C	135 °C	Heat Shrinkable	White	Polyolefin (PO)	0.19 "	2 "	0.45 "		0.5 "
BRADY 3PS-500-2-OR-2	-55 °C	135 °C	Heat Shrinkable	Orange	Polyolefin (PO)	0.19 "	1 "	0.45 "		0.5 "
