PCHC40-R68M-RC
ActiveAllied Components International
.68UH 20%PWR CHIP HIGH CURRENT
PCHC40-R68M-RC
ActiveAllied Components International
.68UH 20%PWR CHIP HIGH CURRENT
Description
General part information
PCHC40-R68M-RC
680 nH Unshielded Wirewound Inductor 12 A 5mOhm Max Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | PCHC40-R68M-RC |
|---|---|
| Current - Saturation (Isat) | 13 A |
| Current Rating | 12 A |
| DC Resistance (DCR) (Max) | 5 mOhm |
| Frequency - Self Resonant | 200 MHz |
| Height - Seated (Max) | 0.25 in |
| Inductance | 680 nH |
| Inductance Frequency - Test | 100 kHz |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Nonstandard |
| Shielding | Unshielded |
| Size / Dimension Length | 0.52 in |
| Size / Dimension Width | 0.39 in |
| Tolerance | 20 % |
| Type | Wirewound |
