MLX92242LUA-AAA-400-BU
ActiveMelexis Technologies NV
MAGNETIC SWITCH LATCH TO92UA
MLX92242LUA-AAA-400-BU
ActiveMelexis Technologies NV
MAGNETIC SWITCH LATCH TO92UA
Description
General part information
MLX92242LUA-AAA-400-BU
Digital Switch Latch, Unipolar Switch Current Source Hall Effect TO-92-3
Technical Specifications
Parameters and characteristics for this part
| Specification | MLX92242LUA-AAA-400-BU |
|---|---|
| Current - Supply (Max) | 17 mA |
| Features | Programmable, Temperature Compensated |
| Function | Unipolar Switch, Latch |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 150 °C |
| Operating Temperature (Min) | -40 °C |
| Output Type | Current Source |
| Package / Case | TO-92-3 Short Body, TO-226-3 |
| Package Name | TO-92-3 |
| Technology | Hall Effect |
| Voltage - Supply (Maximum) | 24 VAC |
| Voltage - Supply (Minimum) | 2.7 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
