IRS26302DJTRPBF

Obsolete

Infineon Technologies

IC GATE DRVR HALF-BRIDGE 44PLCC

Search across all available documentation for this part.

Obsolete

Infineon Technologies

IC GATE DRVR HALF-BRIDGE 44PLCC

Technical Specifications

Parameters and characteristics for this part

Specification	IRS26302DJTRPBF

Channel Type	3-Phase
Driven Configuration	Half-Bridge
Gate Type	N-Channel MOSFET, IGBT
High Side Voltage - Max (Bootstrap) [Max]	600 V
Input Type	Non-Inverting
Logic Voltage - VIL, VIH	2.5 V, 0.8 V
Mounting Type	Surface Mount
Number of Drivers	6
Operating Temperature [Max]	150 °C
Operating Temperature [Min]	-40 °C
Package / Case	32 Leads
Package / Case	44-LCC (J-Lead)
Rise / Fall Time (Typ) [custom]	125 ns
Rise / Fall Time (Typ) [custom]	50 ns
Supplier Device Package	44-PLCC, 32 Leads (16.58x16.58)
Voltage - Supply [Max]	20 V
Voltage - Supply [Min]	10 VDC

Part	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	Driven Configuration	Voltage - Supply [Max]	Voltage - Supply [Min]	Gate Type	Package / Case	Package / Case	Channel Type	Number of Drivers	Input Type	Logic Voltage - VIL, VIH	Supplier Device Package	Rise / Fall Time (Typ) [custom]	Rise / Fall Time (Typ) [custom]	High Side Voltage - Max (Bootstrap) [Max]
Infineon Technologies IRS26302DJTRPBF	Surface Mount	150 °C	-40 °C	Half-Bridge	20 V	10 VDC	IGBT N-Channel MOSFET	32 Leads	44-LCC (J-Lead)	3-Phase	6	Non-Inverting	0.8 V 2.5 V	44-PLCC 32 Leads (16.58x16.58)	125 ns	50 ns	600 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Half-Bridge Gate Driver IC Non-Inverting 44-PLCC, 32 Leads (16.58x16.58)

Technical documentation and resources

No documents available
