VRF2933
ActiveMicrochip Technology
RF MOSFET 50V M177
Deep-Dive with AI
Search across all available documentation for this part.
VRF2933
ActiveMicrochip Technology
RF MOSFET 50V M177
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | VRF2933 | VRF2933 Series |
|---|---|---|
| - | - | |
| Configuration | N-Channel | N-Channel |
| Current - Test | 250 mA | 250 mA |
| Current Rating (Amps) | 2 mA | 2 mA |
| Frequency | 150 MHz | 150 MHz |
| Gain | 25 dB | 25 dB |
| Package / Case | M177 | M177 |
| Power - Output | 300 W | 300 W |
| Supplier Device Package | M177 | M177 |
| Technology | MOSFET (Metal Oxide) | MOSFET (Metal Oxide) |
| Voltage - Rated | 170 V | 170 V |
| Voltage - Test | 50 V | 50 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 164.95 | |
| Microchip Direct | PIZZA BOX | 1 | $ 164.95 | |
| 100 | $ 139.58 | |||
| 250 | $ 133.22 | |||
| 500 | $ 129.60 | |||
| 1000 | $ 125.97 | |||
| 5000 | $ 120.54 | |||
VRF2933 Series
170V RF MOSFET
Description
General part information
VRF2933 Series
The VRF family of RF MOSFETs includes improved replacements for
industry-standard RF transistors. They provide improved ruggedness by
increasing the Bvdss over 30 percent from the industry-standard 125V to 170V
Documents
Technical documentation and resources
