MAL229956182E3
ActiveVishay Dale
ELECTROLYTIC CAPACITOR, 1800 ΜF, 400 V, ± 20%, SNAP-IN, 20000 HOURS @ 105°C
MAL229956182E3
ActiveVishay Dale
ELECTROLYTIC CAPACITOR, 1800 ΜF, 400 V, ± 20%, SNAP-IN, 20000 HOURS @ 105°C
Description
General part information
MAL229956182E3
1800 µF 400 V Aluminum Electrolytic Capacitors Radial, Can - Snap-In - 4 Lead 70mOhm @ 100Hz 5000 Hrs @ 105°C
Technical Specifications
Parameters and characteristics for this part
| Specification | MAL229956182E3 |
|---|---|
| Applications | General Purpose |
| Capacitance | 1800 µF |
| ESR (Equivalent Series Resistance) | 70 mOhm |
| Height - Seated (Max) | 4.016 in |
| Impedance | 50 mOhm |
| Lead Spacing | 0.886 in |
| Lifetime | 5000 Hrs |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -40 °C |
| Package Leads | 4 Leads |
| Package Name | Radial, Can - Snap-In |
| Polarization | Polar |
| Ripple Current | 6.02 A, 9.03 A |
| Size / Dimension Diameter | 1.575 in |
| Tolerance | 20 % |
| Voltage - Rated | 400 V |
