711-172
ObsoleteWAGO Corporation
TRANSFORMER TERMINAL BLOCK; 2-PO
711-172
ObsoleteWAGO Corporation
TRANSFORMER TERMINAL BLOCK; 2-PO
Description
General part information
711-172
2 Position Terminal Block Orange Plug Connection 15.0mm
Technical Specifications
Parameters and characteristics for this part
| Specification | 711-172 |
|---|---|
| Current - IEC | 25 A |
| Height (Max) | 1.378 in |
| Housing Color | Orange |
| Length | 0.925 in |
| Mounting Type | Direct Mount |
| Number of Levels | 1 |
| Number of Positions | 2 |
| Stripping Length (Max) | 10 mm |
| Stripping Length (Min) | 9 mm |
| Terminal Width | 15 mm |
| Termination Style | Push In, Spring |
| Type | Plug Connection |
| Voltage - IEC | 800 V |
