AB1920B991
ActiveAnatech Electronics Inc.
RF FILTER BAND PASS 1.92GHZ MOD
AB1920B991
ActiveAnatech Electronics Inc.
RF FILTER BAND PASS 1.92GHZ MOD
Description
General part information
AB1920B991
1.92GHz Center Frequency Band Pass RF Filter (Radio Frequency) 140MHz Bandwidth 0.25dB Module, SMA Connectors
Technical Specifications
Parameters and characteristics for this part
| Specification | AB1920B991 |
|---|---|
| Bandwidth | 140 MHz |
| Filter Type | Band Pass |
| Frequency (Center) | 1.92 GHz |
| Height (Max) | 1.862 in |
| Insertion Loss | 0.25 dB |
| Mounting Type | Chassis Mount |
| Package / Case | Module, SMA Connectors |
| Size / Dimension Length | 4.6 in |
| Size / Dimension Width | 4.6 in |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
