2903055

Active

Phoenix Contact

CONN MODULE DB25 FEEDTHROUGH

Search across all available documentation for this part.

Active

Phoenix Contact

CONN MODULE DB25 FEEDTHROUGH

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	2903055	DFLK-D25 Series

Convert From (Adapter End)	2 Rows, 25 Pos	2 - 25 Rows
Convert From (Adapter End)	Terminal Blocks, Screwless Connection	Screw Connection, 25 Pos, 2 Rows, Terminal Blocks, Screwless Connection
Convert To (Adapter End)	2 Rows, D-Sub, Male Pins, 25 Pos	D-Sub, Female Sockets, 2 Rows, Male Pins, 25 Pos
Convert To (Adapter End)	-	2 - 25 Rows
Mounting Type	Feed Through, Panel Mount	Feed Through, Panel Mount
Wire Gauge [Max]	24 AWG	24 - 30 AWG
Wire Gauge [Min]	12 AWG	12 AWG

INTERFACE MODULE, DFLK-D25 SUB/B ROHS COMPLIANT: YES

Part	Wire Gauge [Min]	Wire Gauge [Max]	Convert To (Adapter End)	Convert To (Adapter End)	Convert From (Adapter End)	Mounting Type	Convert From (Adapter End)
Phoenix Contact 2280323	12 AWG	24 AWG	2 Rows, 25 positions	D-Sub, Female Sockets	2 Rows, 25 Pos, Screw Connection, Terminal Blocks	Feed Through, Panel Mount
Phoenix Contact 2903055	12 AWG	24 AWG		2 Rows, 25 Pos, D-Sub, Male Pins	Screwless Connection, Terminal Blocks	Feed Through, Panel Mount	2 Rows, 25 Pos
Phoenix Contact 2280310	12 AWG	24 AWG		2 Rows, 25 Pos, D-Sub, Male Pins	2 Rows, 25 Pos, Screw Connection, Terminal Blocks	Feed Through, Panel Mount
Phoenix Contact 2903067	12 AWG	30 AWG	2 Rows, 25 positions	D-Sub, Female Sockets	Screwless Connection, Terminal Blocks	Feed Through, Panel Mount	2 Rows, 25 Pos

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 193.83

General part information

Adapter Terminal Blocks, Screwless Connection, 25 Pos, 2 Rows To D-Sub, Male Pins, 25 Pos, 2 Rows
