Description
General part information
867010-01
60 MHz Bench, Digital Oscilloscopes Thunderbolt™ 3 Interface Display 8 Channel 30V Automation, Frequency Domain Analysis, Playback, Record, Save, Trend, Triggering
Technical Specifications
Parameters and characteristics for this part
| Specification | 867010-01 |
|---|---|
| Analog Channels | 8 |
| Bandwidth | 60 MHz |
| Channel Types | Analog |
| Channels (Count) | 8 |
| Function | Playback, Trend, Frequency Domain Analysis, Save, Triggering, Record, Automation |
| Includes | Thunderbolt™ 3 Male to Male Cable, Power Cord |
| Input Impedance | 1M, 50 |
| Input Impedance | 50 Ω, 1 MOhm |
| Interface | Thunderbolt™ 3 |
| Rise Time (Typ) | 5.83 ns |
| Sampling Rate (Per Second) | 60 MHz |
| Type | Digital, Bench |
| Voltage - Input (Max) | 30 V p-p |
| Voltage - Supply (Maximum) | 240 VAC |
| Voltage - Supply (Minimum) | 100 VAC |
