FN2030-6-06
ActiveTE Connectivity Raychem Cable Protection
LINE FILTER 250VAC 6A CHASSIS
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
FN2030-6-06
ActiveTE Connectivity Raychem Cable Protection
LINE FILTER 250VAC 6A CHASSIS
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | FN2030-6-06 |
|---|---|
| Applications | General Purpose |
| Approval Agency | CSA, ENEC, UR |
| Configuration | Single Stage |
| Current | 6 A |
| Filter Type | Single Phase |
| Frequency - Operating | 400 Hz |
| Inductance | 8 mH |
| Mounting Type | Chassis Mount |
| Operating Temperature [custom] | 100 °C, -25 °C |
| Termination Style | Quick Connect |
| Voltage - Rated AC | 250 V |
Schaffner FN2030 Series
Power Line Filters Single Phase Chassis Mount HP Filter 250VAC, 8A, Wire, <5uA
| Part | Applications | Operating Temperature [custom] | Current | Frequency - Operating | Termination Style | Voltage - Rated DC | Voltage - Rated AC | Configuration | Mounting Type | Inductance | Approval Agency | Filter Type | Frequency - Operating [Max] | Frequency - Operating [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TE Connectivity Raychem Cable Protection | General Purpose | -25 °C 100 °C | 3 A | 400 Hz | Quick Connect | 250 V | 250 V | Single Stage | Chassis Mount | 14 mH | CE CSA ENEC UR | Single Phase | ||
TE Connectivity Raychem Cable Protection | General Purpose | -25 °C 100 °C | 8 A | 400 Hz | Quick Connect | 250 V | 250 V | Single Stage | Chassis Mount | 8 mH | CE CSA ENEC UR | Single Phase | ||
TE Connectivity Raychem Cable Protection | General Purpose | -25 °C 100 °C | 30 A | 400 Hz | Threaded Post (M4) | 250 V | Single Stage | Chassis Mount | 2 mH | CSA ENEC UR | Single Phase | |||
TE Connectivity Raychem Cable Protection | General Purpose | -25 °C 100 °C | 4 A | 400 Hz | Quick Connect | 250 V | Single Stage | Chassis Mount | 14 mH | CSA ENEC UR | Single Phase | |||
TE Connectivity Raychem Cable Protection | General Purpose | -25 °C 100 °C | 6 A | 400 Hz | Quick Connect | 250 V | Single Stage | Chassis Mount | 8 mH | CSA ENEC UR | Single Phase | |||
TE Connectivity Raychem Cable Protection | General Purpose | -25 °C 100 °C | 1 A | 400 Hz | Quick Connect | 250 V | Single Stage | Chassis Mount | 20 mH | CSA ENEC UR | Single Phase | |||
TE Connectivity Raychem Cable Protection | General Purpose | -25 °C 100 °C | 6 A | 400 Hz | Quick Connect | 250 V | 250 V | Single Stage | Chassis Mount | 8 mH | CE CSA ENEC UR | Single Phase | ||
TE Connectivity Raychem Cable Protection | General Purpose | -25 °C 100 °C | 20 A | 400 Hz | Threaded Post (M4) | 250 V | 250 V | Single Stage | Chassis Mount | 4 mH | CE CSA ENEC UR | Single Phase | ||
TE Connectivity Raychem Cable Protection | General Purpose | -25 °C 100 °C | 3 A | 400 Hz | Quick Connect | 250 V | Single Stage | Chassis Mount | 14 mH | CSA ENEC UR | Single Phase | |||
TE Connectivity Raychem Cable Protection | General Purpose | -25 °C 100 °C | 4 A | Quick Connect | 250 V | 250 V | Two Stage | Chassis Mount | 14 mH | CE CSA ENEC UKCA UR | Single Phase | 60 Hz | 50 Hz |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 18.71 | |
| 1 | $ 18.71 | |||
| 10 | $ 18.12 | |||
| 10 | $ 18.12 | |||
| 25 | $ 17.54 | |||
| 25 | $ 17.54 | |||
| 50 | $ 16.95 | |||
| 50 | $ 16.95 | |||
| 100 | $ 15.22 | |||
| 100 | $ 15.22 | |||
| 250 | $ 15.21 | |||
| 250 | $ 15.21 | |||
Description
General part information
Schaffner FN2030 Series
Power Line Filters Single Phase Chassis Mount HP Filter 250VAC, 8A, Wire, <5uA
