Technical Specifications
Parameters and characteristics for this part
| Specification | S24HIS09-2WH2 |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | CE |
| Current - Output (Max) | 222 mA |
| Efficiency | 70 % |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package Leads | 4 Leads |
| Package Name | 7-SIP Module |
| Power (Watts) | 1.99 W |
| Size / Dimension Height | 0.39 in |
| Size / Dimension Length | 0.77 in |
| Size / Dimension Width | 0.28 in |
| Type | Isolated Module |
| Voltage - Input (Max) | 25.2 V |
| Voltage - Input (Min) | 22.8 V |
| Voltage - Isolation | 3 kV |
| Voltage - Output 1 | 9 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | Updated |
|---|---|---|---|---|
| Digikey | Case | 1 | $ 2.82 | 1w |
| 10 | $ 2.74 | |||
| 25 | $ 2.66 | |||
| 50 | $ 2.59 | |||
| 100 | $ 2.52 | |||
| 260 | $ 2.45 | |||
| 500 | $ 2.25 | |||
| 1000 | $ 2.05 | |||
CAD
3D models and CAD resources for this part
Description
General part information
S24HIS09-2WH2
Isolated Module DC DC Converter 1 Output 9V 222mA 22.8V - 25.2V Input
