CM45321R8KSB
ActiveABC Taiwan Electronics Corp.
WOUND CHIP INDUCTOR,4532, 1.80UH
CM45321R8KSB
ActiveABC Taiwan Electronics Corp.
WOUND CHIP INDUCTOR,4532, 1.80UH
Description
General part information
CM45321R8KSB
1.8 µH Unshielded Wirewound Inductor 390 mA 650mOhm Max 1812 (4532 Metric)
Technical Specifications
Parameters and characteristics for this part
| Specification | CM45321R8KSB |
|---|---|
| Current Rating | 390 mA |
| DC Resistance (DCR) (Max) | 650 mOhm |
| Frequency - Self Resonant | 190 MHz |
| Height - Seated (Max) | 0.134 in |
| Inductance | 1.8 µH |
| Inductance Frequency - Test | 7.96 MHz |
| Material - Core | Ferrite |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | 1812 (4532 Metric) |
| Package Name | 1812 |
| Q | 50 |
| Shielding | Unshielded |
| Size / Dimension Length | 0.177 in |
| Size / Dimension Width | 0.126 in |
| Tolerance | 10 % |
| Type | Wirewound |
