5446778
ActivePhoenix Contact
TERM BLOCK HDR 10POS 5.08MM
5446778
ActivePhoenix Contact
TERM BLOCK HDR 10POS 5.08MM
Description
General part information
5446778
10 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.200" (5.08mm) 90°, Right Angle Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | 5446778 |
|---|---|
| Color | Green |
| Contact Tail Length | 0.138 in |
| Current - IEC | 12 A |
| Header Orientation | Right Angle |
| Header Orientation Angle | 90 ° |
| Housing Material | Nylon, Polyamide, PA |
| Insulation Height | 0.339 in |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Through Hole |
| Number of Levels | 1 |
| Number of Positions | 10 |
| Pitch | 5.08 mm |
| Positions Per Level | 10 |
| Termination Style | Solder |
| Type | Shrouded (4 Side), Male Pins, Header |
| Voltage - IEC | 400 V |
