3403.0132.24
ActiveSCHURTER Inc.
FUSE BOARD MNT 3.5A 125VAC 2SMD
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
3403.0132.24
ActiveSCHURTER Inc.
FUSE BOARD MNT 3.5A 125VAC 2SMD
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | 3403.0132.24 | 3403.0132 Series |
|---|---|---|
| Breaking Capacity @ Rated Voltage | 100 A | 100 A |
| Current Rating (Amps) | 3.5 A | 3.5 A |
| Fuse Type | Board Mount | Board Mount |
| Melting I²t | 19 | 19 |
| Mounting Type | Surface Mount | Surface Mount |
| Operating Temperature [Max] | 125 °C | 125 °C |
| Operating Temperature [Min] | -55 °C | -55 °C |
| Package / Case | 2-SMD, J-Lead | 2-SMD, J-Lead |
| Response Time | Slow Blow | Slow Blow |
| Size / Dimension [x] | 0.433 in | 0.433 in |
| Size / Dimension [x] | 11 mm | 11 mm |
| Size / Dimension [y] | 4.6 mm | 4.6 mm |
| Size / Dimension [y] | 0.181 in | 0.181 in |
| Size / Dimension [z] | 3.9 mm | 3.9 mm |
| Size / Dimension [z] | 0.154 in | 0.154 in |
| Voltage Rating - AC | 125 V | 125 V |
3403.0132 Series
FUSE BOARD MNT 3.5A 125VAC 2SMD
| Part | Fuse Type | Breaking Capacity @ Rated Voltage | Current Rating (Amps) | Melting I²t | Operating Temperature [Min] | Operating Temperature [Max] | Package / Case | Mounting Type | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [z] | Response Time | Voltage Rating - AC |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
SCHURTER Inc. 3403.0132.11 | Board Mount | 100 A | 3.5 A | 19 | -55 °C | 125 °C | 2-SMD, J-Lead | Surface Mount | 4.6 mm | 0.181 in | 0.433 in | 11 mm | 3.9 mm | 0.154 in | Slow Blow | 125 V |
SCHURTER Inc. 3403.0132.24 | Board Mount | 100 A | 3.5 A | 19 | -55 °C | 125 °C | 2-SMD, J-Lead | Surface Mount | 4.6 mm | 0.181 in | 0.433 in | 11 mm | 3.9 mm | 0.154 in | Slow Blow | 125 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 1.94 | |
| 5 | $ 1.85 | |||
| 10 | $ 1.76 | |||
| 50 | $ 1.42 | |||
| 100 | $ 1.20 | |||
| 250 | $ 1.17 | |||
| 500 | $ 0.99 | |||
| 1000 | $ 0.88 | |||
| Digi-Reel® | 1 | $ 1.94 | ||
| 5 | $ 1.85 | |||
| 10 | $ 1.76 | |||
| 50 | $ 1.42 | |||
| 100 | $ 1.20 | |||
| 250 | $ 1.17 | |||
| 500 | $ 0.99 | |||
| 1000 | $ 0.88 | |||
| Tape & Reel (TR) | 2000 | $ 0.76 | ||
Description
General part information
3403.0132 Series
3.5 A 125 V AC DC Fuse Board Mount (Cartridge Style Excluded) Surface Mount 2-SMD, J-Lead
