PA06Q-50-1C
ActivePower Dynamics, Inc.
PWR ENT RCPT IEC320-C14 PANEL QC
Deep-Dive with AI
Search across all available documentation for this part.
PA06Q-50-1C
ActivePower Dynamics, Inc.
PWR ENT RCPT IEC320-C14 PANEL QC
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | PA06Q-50-1C |
|---|---|
| Accomodates a Fuse | False |
| Approval Agency | CE, UL, VDE, cUL |
| Connector Style | IEC 320-C14 |
| Connector Type | Male Blades, Receptacle |
| Current Rating - Filter | 6 A |
| Features | Bleed Resistor |
| Filter Type | Filtered (EMI, RFI) - Commercial |
| Mounting Type | Panel Mount, Right Angle, Flange |
| Panel Cutout Dimensions [x] | 30.5 mm |
| Panel Cutout Dimensions [y] | 21.8 mm |
| Termination | 0.25 in |
| Termination | 6.3 mm |
| Termination | Quick Connect |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 11.26 | |
| 10 | $ 11.20 | |||
| 25 | $ 11.15 | |||
Description
General part information
PA06Q-50-1C
Power Entry Connector Receptacle, Male Blades IEC 320-C14 Panel Mount, Flange, Right Angle
Documents
Technical documentation and resources
No documents available
