Specification	0469990919

Connector Type	Header
Contact Type	Male Pin
Current Rating	0 A
Current Rating	Varies by Wire Gauge
Material Flammability Rating	UL94 V-2
Number of Positions	16
Operating Temperature (Max)	80 °C
Operating Temperature (Min)	-40 °C
Voltage Rating	600 V
Voltage Rating (Type)	DC

046999 Series

...

Part	Contact Finish Thickness - Post	Contact Finish Thickness - Mating	Insulation Material	Contact Finish - Post	Material Flammability Rating	Contact Type	Current Rating	Current Rating	Features	Number of Rows	Mounting Type	Row Spacing - Mating	Connector Type	Number of Positions	Voltage Rating	Voltage Rating (Type)	Shrouding	Termination	Style	Insulation Color	Operating Temperature (Min)	Operating Temperature (Max)	Fastening Type	Insulation Height	Pitch - Mating	Number of Positions Loaded	Contact Shape	Contact Finish - Mating	Contact Length - Post	Contact Material	Note	Color	Contact Termination	Pitch	Applications	Pin or Socket	Wire Gauge (AWG) (Min)	Wire Gauge (AWG) (Max)	Contact Finish Thickness	Contact Finish
Molex 0469990024	100 Ąin	100 µin	Glass Filled Nylon 6/6 Polyamide (PA66)	Tin	UL94 V-0	Male Pin	0 A	Varies by Wire Gauge	Board Lock	2	Right Angle Through Hole	0.165 in	Header	24 pos	600 V	DC	Shrouded - 4 Wall	Solder	Board Cable/Wire	Black	-40 °C	105 °C	Locking Ramp	0.38 in	0.165 in	All	Square	Tin	0.14 in	Brass Alloy
Molex 0469990005	100 Ąin	100 µin	Glass Filled Nylon 6/6 Polyamide (PA66)	Tin	UL94 V-2	Male Pin	0 A	Varies by Wire Gauge	Board Lock	2	Right Angle Through Hole	0.165 in	Header	10	600 V	DC	Shrouded - 4 Wall	Solder	Board Cable/Wire	Black	-40 °C	105 °C	Locking Ramp	0.38 in	0.165 in	All	Square	Tin	0.14 in	Brass Alloy
Molex 0469990884			Nylon 6/6 Polyamide (PA66)			Male Pin				1	Panel Mount Snap-In		Plug	2									Locking Ramp								Contacts Not Included	Black	Crimp	0.165 in
Molex 0469990052	100 Ąin	30 µin	Nylon Polyamide (PA)	Tin	UL94 V-0	Male Pin			Board Lock	2	Through Hole	0.165 in	Header	8			Shrouded - 4 Wall	Solder	Board Cable/Wire	Black			Locking Ramp	0.504 in	0.165 in	All	Square	Gold	0.138 in	Brass					General Purpose Industrial Telecommunications
Molex 0469990509					UL94 V-0								Header	1									Friction Lock		0.1 in	All
Molex 0469990340	100 Ąin	100 µin	Nylon 6/6 Polyamide (PA66)	Tin	UL94 V-0	Male Pin			Board Lock	2	Through Hole	0.165 in	Header	12			Shrouded - 4 Wall	Solder	Board Cable/Wire	Black			Locking Ramp	0.504 in	0.165 in	All	Square	Tin	0.138 in	Brass					General Purpose Industrial Telecommunications
Molex 0469990335	100 Ąin	100 µin	Nylon 6/6 Polyamide (PA66)	Tin	UL94 V-0	Male Pin			Board Lock	2	Through Hole	0.165 in	Header	2			Shrouded - 4 Wall	Solder	Board Cable/Wire	Black			Locking Ramp	0.504 in		All	Square	Tin	0.138 in	Brass					General Purpose Industrial Telecommunications
Molex 0469990287
Molex 0469990131	100 Ąin	100 µin	Nylon 6/6 Polyamide (PA66)	Tin	UL94 V-2	Male Pin	0 A	Varies by Wire Gauge		2	Through Hole	0.165 in	Header	12	600 V	DC	Shrouded - 4 Wall	Solder	Board Cable/Wire	Natural	-40 °C	80 °C	Locking Ramp	0.5 in	0.165 in	All	Square	Tin	0.14 in	Brass
Molex 0469990460																																	Crimp			Non-Gendered	24 AWG	30 AWG	100 µin	Tin
