UPD78F0887AGKA-GAJ-G

Active

Renesas Electronics Corporation

8-BIT MICROCONTROLLERS (NON PROMOTION)

Search across all available documentation for this part.

Active

Renesas Electronics Corporation

8-BIT MICROCONTROLLERS (NON PROMOTION)

Technical Specifications

Parameters and characteristics for this part

Specification	UPD78F0887AGKA-GAJ-G

Connectivity	CANbus, I2C, UART/USART, LINbus, 3-Wire SIO
Core Processor	78K/0
Core Size	8-Bit
Data Converters	12, 10 b
Mounting Type	Surface Mount
Number of I/O	55
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	64-LQFP
Peripherals	LVD, WDT, PWM, POR
Program Memory Size	48 KB
Program Memory Type	FLASH
RAM Size	2K x 8
Speed	20 MHz
Supplier Device Package	64-LQFP (12x12)
Voltage - Supply (Vcc/Vdd)	5 V

8-bit Microcontrollers (Non Promotion)

Part	Speed	Core Processor	Operating Temperature [Max]	Operating Temperature [Min]	Connectivity	Package / Case	RAM Size	Number of I/O	Peripherals	Data Converters	Program Memory Type	Mounting Type	Core Size	Voltage - Supply (Vcc/Vdd)	Supplier Device Package	Program Memory Size
Renesas Electronics Corporation UPD78F0887AGKA-GAJ-G	20 MHz	78K/0	85 °C	-40 °C	3-Wire SIO, CANbus, I2C, LINbus, UART/USART	64-LQFP	2K x 8	55	LVD, POR, PWM, WDT	10 b, 12	FLASH	Surface Mount	8-Bit	5 V	64-LQFP (12x12)	48 KB

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

The 78K0/Fx2 is an 8-bit microcontroller with low power consumption for automotive applications.
