Description
General part information
A72ST2470AA00K
0.047 µF Film Capacitor 450V 1500V (1.5kV) Polypropylene (PP), Metallized Axial
Technical Specifications
Parameters and characteristics for this part
| Specification | A72ST2470AA00K |
|---|---|
| Applications | Switching, DV/DT, DC Link, High Frequency, DC Filtering, High Pulse |
| Capacitance | 47 nF |
| Dielectric Material | Metallized, Polypropylene (PP) |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Axial |
| Size / Dimension Diameter | 0.63 in |
| Size / Dimension Length | 1.299 in |
| Termination | PC Pins |
| Tolerance | 10 % |
| Voltage Rating - AC | 450 V |
| Voltage Rating - DC | 1500 V |
