BK/HKP-E-R
ActiveEaton - Electronics Division
FUSE HLDR CART 250V 30A PNL MNT
BK/HKP-E-R
ActiveEaton - Electronics Division
FUSE HLDR CART 250V 30A PNL MNT
Description
General part information
BK/HKP-E-R
Fuse Holder 30 A 250V 1 Circuit Cartridge Panel Mount
Technical Specifications
Parameters and characteristics for this part
| Specification | BK/HKP-E-R |
|---|---|
| Contact Finish | Tin |
| Contact Material | Brass |
| Current Rating | 30 A |
| For Use With/Related Products | 3AG, 1/4" x 1-1/4" (SFE-20) |
| Fuse Diameter | 0.25 in |
| Fuse Length | 1.26 in |
| Fuse Type | Cartridge |
| Fuseholder Type | Holder |
| Mounting Type | Panel Mount |
| Number of Circuits | 1 |
| Termination Style | Solder Lug |
| Voltage | 250 V |
