CTSFW1030F-2R2M
2.2 µH Shielded Wirewound Inductor 9 A 12.5mOhm Max Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | CTSFW1030F-2R2M |
|---|---|
| Current - Saturation (Isat) | 15 A |
| Current Rating | 9 A |
| DC Resistance (DCR) (Max) | 12.5 mOhm |
| Height - Seated (Max) | 0.134 in |
| Inductance | 2.2 µH |
| Inductance Frequency - Test | 100 kHz |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 150 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Nonstandard |
| Shielding | Shielded |
| Size / Dimension Length | 0.413 in |
| Size / Dimension Width | 0.402 in |
| Tolerance | 20 % |
| Type | Wirewound |
