T59EL226M075C0100
ActiveVishay Dale
TANT POLYMER CAPACITOR, 22UF, 75V, 2917 ROHS COMPLIANT: YES
T59EL226M075C0100
ActiveVishay Dale
TANT POLYMER CAPACITOR, 22UF, 75V, 2917 ROHS COMPLIANT: YES
Description
General part information
T59EL226M075C0100
22 µF Molded Tantalum Polymer Capacitor 75 V 2917 (7343 Metric) 100mOhm @ 100kHz
Technical Specifications
Parameters and characteristics for this part
| Specification | T59EL226M075C0100 |
|---|---|
| Capacitance | 22 µF |
| ESR (Equivalent Series Resistance) | 100 mOhm |
| Features | General Purpose |
| Height - Seated (Max) | 0.169 in |
| Lifetime | 1000 Hrs |
| Manufacturer Size Code | EL |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | 2917 (7343 Metric) |
| Size / Dimension Length | 0.287 in |
| Size / Dimension Width | 0.169 in |
| Tolerance | 20 % |
| Type | Molded |
| Voltage - Rated | 75 V |
