5214H-20.000N33DTNOK
ActiveSuzhou Hangjing Elec&Tech Co.,Ltd
OCXO,DIP-14,HCMOS,20MHZ,3.3V,+/-
5214H-20.000N33DTNOK
ActiveSuzhou Hangjing Elec&Tech Co.,Ltd
OCXO,DIP-14,HCMOS,20MHZ,3.3V,+/-
Description
General part information
5214H-20.000N33DTNOK
20 MHz XO (Standard) HCMOS Oscillator 3.3V Enable/Disable 14-DIP Module, 4 Leads
Technical Specifications
Parameters and characteristics for this part
| Specification | 5214H-20.000N33DTNOK |
|---|---|
| Base Resonator | Crystal |
| Frequency | 20 MHz |
| Frequency Stability | 10 ppb |
| Function | Enable, Disable |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Output | HCMOS |
| Package Leads | 4 Leads |
| Package Name | 14-DIP Module, 14-DIP |
| Size / Dimension Length | 0.787 in |
| Size / Dimension Width | 0.512 in |
| Type | OCXO, XO (Standard) |
| Voltage - Supply | 3.3 V |
