Pluggable Terminal Blocks 13 Pos 3.81mm pitch Through Hole Header
Technical documentation and resources
Parameters and characteristics commom to parts in this series
| Specification | 1961326 | MCDV Series |
|---|---|---|
| Color | Black | Green, Black |
| Contact Mating Finish | Tin | Tin |
| Contact Tail Length | 3.5 mm | 3.4 - 3.5 mm |
| Contact Tail Length | 0.138 in | 0.134 - 0.138 in |
| Current - IEC | 4 A | 4 - 8 A |
| Current - UL | - | 8 A |
| Features | - | Mating Flange |
| Header Orientation | Vertical | Vertical |
| Housing Material | Polyamide (PA), Nylon | Polyamide (PA), Nylon |
| Insulation Height | 0.689 in | 0.689 - 0.862 in |
| Insulation Height | 17.5 mm | 17.5 - 21.89 mm |
| Material Flammability Rating | UL94 V-0 | UL94 V-0 |
| Mounting Type | Through Hole | Through Hole |
| Number of Levels | 2 | 2 |
| Number of Positions | 20 | 12 - 20 |
| Pitch [x] | 0.098 in | 0.098 - 0.15 in |
| Pitch [x] | 2.5 mm | 2.5 - 3.81 mm |
| Positions Per Level | 10 | 6 - 10 |
| Termination Style | Solder | Solder |
| Type | Header, Male Pins, Shrouded (4 Side) | Header, Male Pins, Shrouded (4 Side) |
| Voltage - IEC | 160 V | 160 - 320 V |
| Voltage - UL | - | 300 V |
Pluggable Terminal Blocks 13 Pos 3.81mm pitch Through Hole Header
| Part | Housing Material | Header Orientation | Material Flammability Rating | Contact Mating Finish | Color | Current - IEC | Type | Current - UL | Number of Positions | Number of Levels | Contact Tail Length | Contact Tail Length | Mounting Type | Insulation Height | Insulation Height | Pitch [x] | Pitch [x] | Voltage - UL | Positions Per Level | Features | Voltage - IEC | Termination Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Phoenix Contact 1842801 | Polyamide (PA), Nylon | Vertical | UL94 V-0 | Tin | Green | 8 A | Header, Male Pins, Shrouded (4 Side) | 8 A | 12 | 2 | 3.4 mm | 0.134 in | Through Hole | 21.89 mm | 0.862 in | 0.15 in | 3.81 mm | 300 V | 6 | Mating Flange | 320 V | Solder |
Phoenix Contact 1961326 | Polyamide (PA), Nylon | Vertical | UL94 V-0 | Tin | Black | 4 A | Header, Male Pins, Shrouded (4 Side) | 20 | 2 | 3.5 mm | 0.138 in | Through Hole | 17.5 mm | 0.689 in | 0.098 in | 2.5 mm | 10 | 160 V | Solder |
