83395 002500

Active

Belden Inc.

CABLE 3COND 22AWG RED SHLD

Search across all available documentation for this part.

Active

Belden Inc.

CABLE 3COND 22AWG RED SHLD

Technical Specifications

Parameters and characteristics for this part

Specification	83395 002500

Cable Type	Multi-Conductor
Conductor Insulation	Fluorinated Ethylene-Propylene (FEP)
Conductor Material	Copper, Tinned
Conductor Strand [custom]	7
Conductor Strand [custom]	30 AWG
Features	Drain Wire
Jacket (Insulation) Diameter [diameter]	0.208 in
Jacket (Insulation) Diameter [diameter]	5.28 mm
Jacket (Insulation) Material	Silicone Rubber
Jacket (Insulation) Thickness	0.8 mm
Jacket (Insulation) Thickness	0.0315 in
Jacket Color	Red
Length [x]	500 '
Length [x]	152.4 m
Number of Conductors	3
Operating Temperature [Max]	150 °C
Operating Temperature [Min]	-70 °C
Shield Coverage	100 %
Shield Material	Aluminum
Shield Type	Foil
Usage	Control, Communication, Instrumentation
Wire Gauge	22 AWG

Part	Cable Type	Conductor Insulation	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Operating Temperature [Max]	Operating Temperature [Min]	Jacket Color	Number of Conductors	Conductor Strand [custom]	Conductor Strand [custom]	Shield Material	Shield Coverage	Length [x]	Length [x]	Shield Type	Wire Gauge	Usage	Features	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Conductor Material	Jacket (Insulation) Material
Belden Inc. 83395 002100	Multi-Conductor	Fluorinated Ethylene-Propylene (FEP)	0.8 mm	0.0315 in	150 °C	-70 °C	Red	3	7	30 AWG	Aluminum	100 %	30.5 m	100 ft	Foil	22 AWG	Communication Control Instrumentation	Drain Wire	0.208 in	5.28 mm	Copper Tinned	Silicone Rubber
Belden Inc. 83395 002500	Multi-Conductor	Fluorinated Ethylene-Propylene (FEP)	0.8 mm	0.0315 in	150 °C	-70 °C	Red	3	7	30 AWG	Aluminum	100 %	152.4 m	500 '	Foil	22 AWG	Communication Control Instrumentation	Drain Wire	0.208 in	5.28 mm	Copper Tinned	Silicone Rubber

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	500	$ 11.62

General part information

3 Conductor Multi-Conductor Cable Red 22 AWG Foil 500.0' (152.4m)
