CDBFN140-HF

Active

Comchip Technology

DIODE SCHOTTKY 40V 1A SOD323

Search across all available documentation for this part.

Active

Comchip Technology

DIODE SCHOTTKY 40V 1A SOD323

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Diode 40 V 1A Surface Mount SOD-323

Technical documentation and resources

Specification	CDBFN140-HF	CDBFN140 Series

Capacitance @ Vr, F	120 pF	120 pF
Current - Average Rectified (Io)	1 A	1 A
Current - Reverse Leakage @ Vr	500 µA	500 µA
Mounting Type	Surface Mount	Surface Mount
Operating Temperature - Junction [Max]	125 °C	125 °C
Operating Temperature - Junction [Min]	-50 °C	-50 °C
Package / Case	SOD-323F, SC-90	SOD-323F, SC-90
Speed	200 mA, 500 ns	200 - 500 mA
Supplier Device Package	SOD-323	SOD-323
Technology	Schottky	Schottky
Voltage - DC Reverse (Vr) (Max) [Max]	40 V	40 V
Voltage - Forward (Vf) (Max) @ If	550 mV	550 mV

Part	Operating Temperature - Junction [Max]	Operating Temperature - Junction [Min]	Supplier Device Package	Current - Average Rectified (Io)	Voltage - Forward (Vf) (Max) @ If	Voltage - DC Reverse (Vr) (Max) [Max]	Mounting Type	Capacitance @ Vr, F	Current - Reverse Leakage @ Vr	Speed	Package / Case	Technology
Comchip Technology CDBFN140-HF	125 °C	-50 °C	SOD-323	1 A	550 mV	40 V	Surface Mount	120 pF	500 µA	200 mA, 500 ns	SC-90, SOD-323F	Schottky
Comchip Technology CDBFN140-G	125 °C	-50 °C	SOD-323	1 A	550 mV	40 V	Surface Mount	120 pF	500 µA	200 mA, 500 ns	SC-90, SOD-323F	Schottky
