Description
General part information
0604MPU188B
#6-32 Flat Head Machine Screw Phillips Drive Stainless Steel
Technical Specifications
Parameters and characteristics for this part
| Specification | 0604MPU188B |
|---|---|
| Drive Type | Phillips |
| Features | Undercut |
| Head Diameter | 0.25 in |
| Head Height | 0.054 in |
| Length - Below Head | 0.25 in |
| Length - Overall | 0.304 in |
| Material | Stainless Steel |
| Plating | Black Oxide |
| Screw Head Type | Flat Head |
| Thread Size (Max) | 32 mm |
| Thread Size (Min) | 6 mm |
| Type | Machine Screw |
