1613595
LTBPhoenix Contact
CIRCULAR METRIC CONNECTORS ST-8EP1N8A6100S
1613595
LTBPhoenix Contact
CIRCULAR METRIC CONNECTORS ST-8EP1N8A6100S
Description
General part information
1613595
9 (5 + 3 Power + PE) Position Circular Connector Receptacle Housing Panel Mount
Technical Specifications
Parameters and characteristics for this part
| Specification | 1613595 |
|---|---|
| Connector Type | Receptacle Housing |
| Contact Shape | Circular |
| Contact Size | 0.6 mm |
| Contact Size (Power) | 1 mm |
| Contact Type | Crimp |
| Fastening Type | Push-Twist |
| Housing Color | Silver |
| Ingress Protection Description | Waterproof, Dust Tight |
| Ingress Protection IP Rating | IP67 |
| Mounting Feature | Rear Side Nut, Bulkhead |
| Mounting Type | Panel Mount |
| Note | Contacts Not Included |
| Number of Positions | 9 |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Orientation | N (Normal) |
| Position Types | PE, Power |
| Shell Material | Metal |
| Shell Size - Insert | M17-9 |
| Shielding | Shielded |
| Type | For Male Pins |
