Specification	1218SQ-12(6)

Adhesive	Acrylic
Backing	Polyimide
Carrier	Polyimide
Color	Amber
Length	12 in
Shelf Life	60 Months
Shelf Life Start	Date of Manufacture
Tape Type	Insulating, High Temperature
Temperature Range (Single)	180 °C
Thickness	0.003 in
Thickness - Adhesive	0.002 in
Thickness - Backing, Carrier	0.001 in
Usage	Insulating, High Temperature
Width	12 in

1218 Series

...

Part	Shelf Life Start	Shelf Life	Thickness	Temperature Range (Max)	Thickness - Backing, Carrier	Adhesive	Length	Thickness - Adhesive	Width	Tape Type	Backing	Carrier	Color	Length (yd)	Length (ft)
3M (TC) 3M 1218 1" X 1.5"-100	Date of Manufacture	60 Months	0.003 in	356 °F	0.001 in	Acrylic	1.5 in	0.002 in	1 in	High Temperature Insulating	Polyimide	Polyimide	Amber
3M (TC) 3M 1218 5" X 1.25"-25	Date of Manufacture	60 Months	0.003 in	356 °F	0.001 in	Acrylic	1.25 in	0.002 in	5 in	High Temperature Insulating	Polyimide	Polyimide	Amber
3M (TC) 3M 1218 1.75" X 36YD	Date of Manufacture	60 Months	0.003 in	356 °F	0.001 in	Acrylic		0.002 in	1.75 in	High Temperature Insulating	Polyimide	Polyimide	Amber	36 yd	108 ft
3M (TC) 3M 1218 1.5" X 5"-100	Date of Manufacture	60 Months	0.003 in	356 °F	0.001 in	Acrylic	5 in	0.002 in	1.5 in	High Temperature Insulating	Polyimide	Polyimide	Amber
3M (TC) 1218CIR-0.438(2000)	Date of Manufacture	60 Months	0.003 in	356 °F	0.001 in	Acrylic		0.002 in	0.44 in	High Temperature Insulating	Polyimide	Polyimide	Amber
3M (TC) 3M 1218 1" X 5"-100	Date of Manufacture	60 Months	0.003 in	356 °F	0.001 in	Acrylic	5 in	0.002 in	1 in	High Temperature Insulating	Polyimide	Polyimide	Amber
3M (TC) 3M 1218 1.625" X 36YD	Date of Manufacture	60 Months	0.003 in	356 °F	0.001 in	Acrylic		0.002 in	1.63 in	High Temperature Insulating	Polyimide	Polyimide	Amber	36 yd	108 ft
3M (TC) 3M 1218 6" X 10.5"-25	Date of Manufacture	60 Months	0.003 in	356 °F	0.001 in	Acrylic	10.5 in	0.002 in	6 in	High Temperature Insulating	Polyimide	Polyimide	Amber
3M (TC) 1218-0.125-36	Date of Manufacture	60 Months	0.003 in	356 °F	0.001 in	Acrylic		0.002 in	0.13 in	High Temperature Insulating	Polyimide	Polyimide	Amber	36 yd	108 ft
3M (TC) 3M 1218 4" X 8.625"-25	Date of Manufacture	60 Months	0.003 in	356 °F	0.001 in	Acrylic	8.63 in	0.002 in	4 in	High Temperature Insulating	Polyimide	Polyimide	Amber

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

1218SQ-12(6) | Datasheet
