MRF 200-BULK
ObsoleteBel Fuse Inc.
FUSE BRD MNT 200MA 250VAC RADIAL
MRF 200-BULK
ObsoleteBel Fuse Inc.
FUSE BRD MNT 200MA 250VAC RADIAL
Description
General part information
MRF 200-BULK
200 mA 250 V AC DC Fuse Board Mount (Cartridge Style Excluded) Through Hole Radial, Can, Vertical
Technical Specifications
Parameters and characteristics for this part
| Specification | MRF 200-BULK |
|---|---|
| Approval Agency | CE, AEC-Q200, CSA, VDE, SEMKO, cULus |
| Breaking Capacity | 35 A |
| Current Rating | 0.2 A |
| DC Cold Resistance | 1.7 Ohms |
| Fuse Type | Board Mount (Cartridge Style Excluded) |
| Melting I²t | 0.027 |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Can, Vertical, Radial |
| Response Time | Fast Blow |
| Size / Dimension Diameter | 0.329 in |
| Size / Dimension Height | 0.303 in |
| Voltage Rating - AC | 250 V |
