T1681URO-20C000312U1930
ActiveHarvatek Corporation
LED RED CLEAR 4PLCC SMD
T1681URO-20C000312U1930
ActiveHarvatek Corporation
LED RED CLEAR 4PLCC SMD
Description
General part information
T1681URO-20C000312U1930
Red 631nm LED Indication - Discrete 2V 4-PLCC
Technical Specifications
Parameters and characteristics for this part
| Specification | T1681URO-20C000312U1930 |
|---|---|
| Color | Red |
| Current - Test | 20 mA |
| Height (Max) | 2 mm |
| Lens Diameter | 2 mm |
| Lens Style | Round, Flat Top |
| Lens Transparency | Clear |
| Millicandela Rating | 120 mcd |
| Mounting Type | Surface Mount |
| Package / Case | 4-PLCC |
| Package Name | 4-PLCC |
| Viewing Angle | 120 ° |
| Voltage - Forward (Vf) (Typ) | 2 V |
| Wavelength - Dominant | 631 nm |
| Wavelength - Peak | 639 nm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
