HD90-Q01

Active

Auer Signal

COMPLETE UNIT ORG/RED 2STACK

Search across all available documentation for this part.

Active

Auer Signal

COMPLETE UNIT ORG/RED 2STACK

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	HD90-Q01	HD90 Series

Function - Lighting	Steady	Steady
Ingress Protection	IP65 - Dust Tight, Water Resistant	IP65 - Dust Tight, Water Resistant
Light Color	Orange, Red	Red, Green, Orange
Number of Stacks	2	2 - 3
Operating Temperature [Max]	50 °C	50 °C
Operating Temperature [Min]	-25 °C	-25 °C
Termination Style	Wire Leads	Wire Leads
Type	Complete Unit	Complete Unit
Voltage - Supply	24 VAC	24 VAC
Voltage - Supply	-	240 VAC
Voltage - Supply	-	230 VAC

COMPLETE UNIT GR/ORG/R STEADY

Part	Number of Stacks	Ingress Protection	Function - Lighting	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Supply [Max]	Voltage - Supply [Min]	Type	Termination Style	Light Color	Voltage - Supply
Auer Signal HD90-Q81	3	IP65 - Dust Tight, Water Resistant	Steady	50 °C	-25 °C	240 VAC	230 VAC	Complete Unit	Wire Leads	Green, Orange, Red
Auer Signal HD90-Q31	3	IP65 - Dust Tight, Water Resistant	Steady	50 °C	-25 °C			Complete Unit	Wire Leads	Green, Orange, Red	24 VAC
Auer Signal HD90-Q01	2	IP65 - Dust Tight, Water Resistant	Steady	50 °C	-25 °C			Complete Unit	Wire Leads	Orange, Red	24 VAC

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 286.32

General part information

Stack Light Complete Unit Orange, Red LED Wire Leads
