Description

General part information

R413F133050D0K

3300 pF Film Capacitor 300V 1200V (1.2kV) Polypropylene (PP), Metallized Radial

Technical Specifications

Parameters and characteristics for this part

SpecificationR413F133050D0K
ApplicationsHigh Pulse, RFI Suppression, DV/DT, Automotive, EMI
Capacitance3300 pF
Dielectric MaterialMetallized, Polypropylene (PP)
Height - Seated (Max)0.437 in
Lead Spacing0.394 in
Mounting TypeThrough Hole
Operating Temperature (Max)125 °C
Operating Temperature (Min)-40 °C
Package / CaseRadial
RatingsAEC-Q200, Y2, X1
Size / Dimension Length0.512 in
Size / Dimension Width0.197 in
TerminationPC Pins
Tolerance10 %
Voltage Rating - AC300 V
Voltage Rating - DC1200 V
